Everything you need to get moving.

<p class="rteBlock">Net Power 15.7kW </p><p class="rteBlock">Net Power - 2,400 rpm - ISO 9249, 80/1269/EEC  15.7kW</p><p class="rteBlock">Gross Power - SAE J1995:2014 16.1kW</p><p class="rteBlock">Bore 77mm</p><p class="rteBlock">Stroke 81mm</p><p class="rteBlock">Displacement 1.1l</p>

<p class="rteBlock">Operating Weight 2029kg</p><p class="rteBlock">Minimum Operating Weight with Canopy 1725kg</p><p class="rteBlock">Maximum Operating Weight with Canopy 1905kg</p><p class="rteBlock">Minimum Operating Weight with Cab 1848kg</p><p class="rteBlock">Maximum Operating Weight with Cab 2029kg</p><p class="rteBlock">EU: CE Plate Weight with Canopy 1880kg</p><p class="rteBlock">EU: CE Plate Weight with Cab 2000kg</p>

<p class="rteBlock">Long Stick 8kg</p><p class="rteBlock">Steel Tracks 50kg</p><p class="rteBlock">Expandable Undercarriage 123kg</p>

<p class="rteBlock">Travel Speed - High 4.4km/h</p><p class="rteBlock">Travel Speed - Low 2.9km/h</p><p class="rteBlock">Maximum Traction Force - High Speed 11.9kN</p><p class="rteBlock">Maximum Traction Force - Low Speed 18.4kN</p><p class="rteBlock">Ground Pressure - Minimum Weight 26.8kPa</p><p class="rteBlock">Ground Pressure - Maximum Weight 29.6kPa</p>

<p class="rteBlock">Cooling System 3.9l</p><p class="rteBlock">Engine Oil 4.4l</p><p class="rteBlock">Fuel Tank 26l</p><p class="rteBlock">Hydraulic Tank 18l</p><p class="rteBlock">Hydraulic System 26l</p>

<p class="rteBlock">Pump Flow at 2,400 rpm 66L/min</p><p class="rteBlock">Operating Pressure - Equipment 245bar</p><p class="rteBlock">Operating Pressure - Travel 245bar</p><p class="rteBlock">Operating Pressure - Swing 147bar</p><p class="rteBlock">Auxiliary Circuit - Primary - Flow 33L/min</p><p class="rteBlock">Auxiliary Circuit - Primary - Pressure 245bar</p><p class="rteBlock">Auxiliary Circuit - Secondary - Flow 14L/min</p><p class="rteBlock">Auxiliary Circuit - Secondary - Pressure 245bar</p><p class="rteBlock">Digging Force - Stick - Standard 11.3kN</p><p class="rteBlock">Digging Force - Stick - Long 9.8kN</p><p class="rteBlock">Digging Force - Bucket 19.6kN</p>

<p class="rteBlock">Machine Swing Speed 9.8r/min</p>

<p class="rteBlock">Width 990mm</p><p class="rteBlock">Height 225mm</p>

<p class="rteBlock">Dig Depth 2370mm</p><p class="rteBlock">Vertical Wall 1850mm</p><p class="rteBlock">Maximum Reach - Ground Level 3800mm</p><p class="rteBlock">Maximum Reach 3870mm</p><p class="rteBlock">Maximum Dig Height 3550mm</p><p class="rteBlock">Maximum Dump Clearance 2560mm</p><p class="rteBlock">Boom In Reach 1420mm</p><p class="rteBlock">Tail Swing 995mm</p><p class="rteBlock">Maximum Blade Height 270mm</p><p class="rteBlock">Maximum Blade Depth 265mm</p><p class="rteBlock">Boom Height - Shipping Position 1070mm</p><p class="rteBlock">O/A Shipping Height 2300mm</p><p class="rteBlock">Swing Bearing - Height 442mm</p><p class="rteBlock">O/A Undercarriage Length 1590mm</p><p class="rteBlock">Overall Shipping Length 3720mm</p><p class="rteBlock">Boom Swing - Right 50°</p><p class="rteBlock">Boom Swing - Left 65°</p><p class="rteBlock">Track Belt/Shoe Width 230mm</p><p class="rteBlock">Track Width - Retracted 990mm</p><p class="rteBlock">Track Width - Expanded 1300mm</p><p class="rteBlock">Minimum Ground Clearance Below Undercarriage 150mm</p><p class="rteBlock">Stick Length 960mm</p>

<p class="rteBlock">Dig Depth 2570mm</p><p class="rteBlock">Vertical Wall 1940mm</p><p class="rteBlock">Maximum Reach - Ground Level 3960mm</p><p class="rteBlock">Maximum Reach 4030mm</p><p class="rteBlock">Maximum Dig Height 3620mm</p><p class="rteBlock">Maximum Dump Clearance 2640mm</p><p class="rteBlock">Boom In Reach 1420mm</p><p class="rteBlock">Tail Swing 995mm</p><p class="rteBlock">Maximum Blade Height 270mm</p><p class="rteBlock">Maximum Blade Depth 265mm</p><p class="rteBlock">Boom Height - Shipping Position 1020mm</p><p class="rteBlock">O/A Shipping Height 2300mm</p><p class="rteBlock">Swing Bearing - Height 442mm</p><p class="rteBlock">O/A Undercarriage Length 1590mm</p><p class="rteBlock">Overall Shipping Length 3710mm</p><p class="rteBlock">Boom Swing - Right 50°</p><p class="rteBlock">Boom Swing - Left 65°</p><p class="rteBlock">Track Belt/Shoe Width 230mm</p><p class="rteBlock">Track Width - Retracted 990mm</p><p class="rteBlock">Track Width - Expanded 1300mm</p><p class="rteBlock">Minimum Ground Clearance Below Undercarriage 150mm</p><p class="rteBlock">Stick Length 1160mm</p>

<p class="rteBlock">Operator Sound Pressure (ISO 6396:2008) 72dB(A)</p><p class="rteBlock">Average Exterior Sound Pressure (ISO 6395:2008) 99dB(A)</p>
